The dmXLAN buddy is a 2-port DMX – Ethernet node that supports Art-Net / sACN / Strand shownet and is fully supported by the dmXLAN software. Power over USB port Supports sACN, Art-Net & Shownet Ports can act as input or output Simple programming through specific software application (Buddy Setup) Compatible with dmXLAN v4 software as any ELC dmXLAN node The Integrated web page will convert the device into a simple DMX controller – just like the famous ELC focusHAND remote. Read more -
DLN8GBX- 8 fully programmable DMX ports and a dual Gigabit port switch with user interface. The node offers data splitting, merging, soft patching and backup when programmed using ELC’s dmXLAN software. All DMX ports are fully-isolated. Every DMX port has an RGB LED indicator which can be programmed via the dmXLAN software. The output of the DMX ports is measured continuously and detected changes and errors are appearing on the node’s display and in dmXLAN. Features: Active output measurement RGB LED for every DMX port 8 Bi-directional DMX ports on the front panel, RDM compatible Supports sACN, Art-Net & Shownet Remote programming and monitoring and fixture parameter override DMX Input normal or backup DMX Output normal, HTP, Priority merging, Softpatch (channel by channel), programmable merging with DMX channel control Local control via colour touchscreen, rotary encoder/selector pushbutton Support for WYSIWYG, ESP, Capture Read more -
The dmXLAN switchGBx 18 has been specifically designed for live entertainment applications where a mixture of data protocols would overload and saturate commercially-available network switches. The ELC switches forms the backbone of the network distribution system. Easily create virtual networks for specific applications, like sound, video, lighting etc. Setup fast redundant loops with fault reporting. 16 Ethernet ports with speed up to 1GB, and 2 SFP cages for fiberoptic capable of speeds up to 2.5Gbps. The ethernet ports on the front panel support PoE and a RGB LED to indicate the status and the programmed VLAN. Easy programming on local colour touch screen or remotely with our dmXLAN V4 software. Features: Real-time backup loops Local colour touch screen and rotary encoder 8 1Gbps Network Ports with PoE (802.3af-2003 Standard) on the front with RGB LED 8 1Gbps Network Ports on the rear 2 SFP cages for Fiber Optic modules up to 2.5 Gbps Supported by dmXLAN V4 software Partition of the network into separate VLANs DANTE Compatible Can act as master for the dmXLAN nodeGBx 8 Read more -
