Mini-B

Mini-B is the smallest LED beam light ever made by Claypaky for the professional market. Although it weighs just 7 Kg and measures only 34 cm, Mini-B features the most advanced, modern optical and electronic technology. The light source is based on 40 Watt Osram RGBW LEDs, the same ones fitted in the new Claypaky HY B-EYE.

Description

Mini-B features a wide zoom, ranging from 4° to 54° that makes this little luminaire extremely versatile. At the narrow angle, the beam produced is very solid and concentrated, superb for aerial effects. At full aperture, the Mini-B becomes an excellent wash light and it can replace much heavier and bulkier equipment, on stages, in TV studios, at multi-purpose venues and at clubs.
The Mini-B’s central LED may be controlled separately from the external ring of LEDs, making it ideal for graphic lighting effects too. More than fifty pre-installed effects/colour macros, 2500K-8000K colour temperature control, a 16 bit dimmer with four curves, an electronic strobe @ 25 f/sec, and Ethernet access complete this highly professional tool.

Features:

  • Light Source: 7 x RGBW Osram Ostar LEDs
  • LED power rating: 40 W
  • Extremely compact and lightweight
  • Highly efficient light output, very low power consumption
  • Very high-speed Pan and Tilt movements
  • 4°-54° Zoom range
  • Independent control of the central LED
  • Pre-installed effects/colour macros
  • 2500K – 8000K colour temperature control
  • 16 bit dimmer with 4 curves
  • Electronic strobe @ 25 f/sec
  • Ethernet access

POWER SUPPLIES
-100-240V 50/60Hz

INPUT POWER
-375 VA at 230V 50Hz

LIGHT SOURCE
-7x Osram 40W RGBW LEDs
-Life: 50,000 hrs

OPTICS
-4°-54°  Electronic Zoom Range

EFFECTS SECTION
-Pixel Patterning Macros with enhanced control
-0-100% linear electronic dimmer
-Dedicated channel for colour temperature setting
-White CT Emulation 2500-8000K
-Strobe effect: from 1 flash/sec; Fast Strobe: 25 flash/sec

CONTROL AND PROGRAMMING
-DMX protocol signal: USITT DMX 512
-Art-Net / RDM
-Display: Graphic LCD backlit b/w Display
-Pan/Tilt Resolution: 16 bit
-Dimmer Resolution: 16 bit
-DMX signal connection: 5 pole XLR input and output
-Software upload through DMX input

BODY
-Aluminum structure with die-cast plastic cover
-Two side handles for transportation (Optional)

MOVING BODY
-Movement by means of two stepper motors, controlled by microprocessor
-Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit
-Travel:
– PAN = 540°
– TILT = 260°

ELECTRONICS
-Long-life auto-charging buffer battery
-Preset macro color
-Function reset controllable from a central control unit
-Menu-driven internal self-test function
-Ethernet ready with RJ45 socket
-Display: backlit black-and-white graphic LCD display
-Electronic check-up of every single parameter with error alarm
-DMX level monitoring on each channel
-Automatic internal data transmission error diagnostics
-Firmware transfer from one light to another

SAFETY DEVICES
-Automatic power safety derating in case of overheat of the LED board
-Forced ventilation

WORKING POSITION
-Working in any position
-Hanging system: with fast-lock omega clamp (1/4 turn) on the base (Optional)



Claypaky_MiniB_leaflet.pdf    1006.4 KB
Mini-B_Datasheet_09.2019.pdf    190.97 KB
Mini-B_InstructionManual_03.2019.pdf    6.92 MB
Mini-B_Photometrics_08.2019.pdf    1.18 MB
MiniB_UserMenu_05.2019.pdf    363.45 KB
