RUSH Scanner 1 LED

The RUSH Scanner 1 LED is designed to enable lighting designers to boost the wow factor and energise crowds with high-speed mid-air looks in a variety of entertainment venues and nightclubs.

OUT OF STOCK – Please call your nearest office for more information or a recommended replacement product.

SEND ENQUIRY

Description

This fixture delivers high output via sharp optics and is packed with eye-catching effects.  With its high-speed pan and tilt capabilities, the RUSH Scanner 1 LED is ideal for creating dramatic atmospheres and boosting energy levels on cruise ships, in dance clubs and other nightlife venues.

Compact size, low weight, rugged construction and long-life LEDs also make the RUSH Scanner 1 LED a favourite for rental companies seeking to produce once-in-a-lifetime memorable events through powerful, dynamic lighting effects.

• High-power, long-life 90 W white LED engine
• Effects include two gobo wheels. two color wheels and a 3-facet prism
• Sharp projections with motorized focus
• DMX control and standalone operation
• Auto trig and music trig standalone modes
• Compact size and rugged construction

Physical

Length: 588 mm (23.1 in.)
Width: 303 mm (11.9 in.)
Height: 193 mm (7.6 in.)
Weight: 9.6 kg 21.1 lbs.)

 Dynamic Effects
Color wheel 1: 8 colors plus open, rotation with variable direction and speed
Color wheel 2: 8 colors (incl. 1 x UV, 2 x CTC) plus open, rotation with variable
direction and speed
Rotating gobo wheel: 6 rotating/indexing gobos plus open
Fixed gobo wheel: 7 gobos plus open
Electronic ‘shutter’ effect: Strobe, pulse effects, instant open and blackout
Prism: Indexing and rotation with variable direction and speed
Focus: Motorized
Electronic dimming: 0 – 100%, four dimming curve options
Pan: 170°, coarse & fine control
Tilt: 75°, coarse & fine control
Control and Programming
Control options: DMX, standalone, synchronized master/slave
DMX channels: 16
Standalone trigger options: Sound activation (music trig), auto trig
Standalone sequences: 9 pre-programmed shows
Standalone memory: 20 scenes
Music trig sensitivity: Adjustable
Setting and addressing: Control panel with backlit LCD display
DMX compliance: USITT DMX512/1990
Optics
Light source: 90 W LED engine
beam angle: 14°
Minimum LED lifetime: 30 000 hours (to >70% luminous output)*
Rotating gobo size: 24 mm (0.94 in.)
Rotating gobo image size: 20 mm (0.79 in.)
Construction
Color: Black
Housing: High-impact flame-retardant thermoplastic
Protection rating: IP20
Installation
Mounting points: Adjustable bracket, surface or truss mount
Location: Indoor use only, must be fastened to surface or structure
Orientation: Any
Connections
 AC power in/thru: Neutrik PowerCon
DMX data in/out: 3-pin and 5-pin locking XLR

2 RUSH Scanner 1 LED.pdf 137.32 KB
