Exterior PixLine 40 RGB

The Exterior PixLine 40 is a linear LED video fixture for media facades and creative installations.


The Exterior PixLine 40 is driven by the Martin P3 System Controller family for easy setup and video display, and it is also backwards compatible with DMX. The fixtures can be fully customized in terms of length and colour to match every installation requirement, while the power source is hidden.

  • Wide range of pixel pitch, lens and diffuser options for the flexibility of look
  • Fully outdoor-rated and customizable in terms of length and colour
  • Easy setup and cabling for clean installation
  • 40 mm pixel pitch
  • 62 cd per meter calibrated
  • 40 lumen per foot calibrated
  • High-quality 16-bit per colour image processing technology
  • Pixel-level brightness and colour calibration for optimal image quality
  • P3/DMX controllable (automatic protocol detection)
  • Intuitive mapping and addressing via P3 System Controller
  • Combined power/data input (single cable for power and data input)
  • Supported by integrated power and data processor (P3 PowerPort 1500 or P3 PowerPort 1000 IP) and simple cabling system
  • Available in standard length of 1270 mm and 310 mm (customized lengths also available)

The exterior PixLine 40 comes in  310mm and 1270mm lengths with three different diffusers:

MAREXT240- Square diffuser 310mm

MAREXT241- Round diffuser 310mm

MAREXT242- Clear diffuser 310mm

MAREXT250- Square diffuser 1270mm

MAREXT251- Round diffuser 1270mm

MAREXT253- Clear diffuser 1270mm


There are no downloads available for this product!
