VersaPar

Categories: , , , , SKU: MUSPAR110

VersaPar is a LED zoom PAR designed for rental companies. The multi-purpose concept combining high brightness, wide zoom range and advanced colour mixing make this a unique fixture.

Description

VersaPar is equipped with 10° – 60° unrivalled zoom range, high efficiency, perfect chromatic uniformity, HD dimming technology and totally silent operation.



Features:

  • 12x10W RGBW/FC LED
  • Wide zoom range from 10° – 60° (1:6 zoom)
  • HD dimming with selectable PWM
  • Silent operation for studio application

LIGHT SOURCE

  • Source: 12x10W RGBW / FC LEDs
  • Luminous flux: (10°) 1’450 lm – (60°) 1’786lm
  • Lux: (10°) 3’144 lx – (60°) 249lx @5 m full
  • Source life expectancy: > 50.000 h



OPTICS

  • Zoom: 10° – 60° motorised linear zoom
  • Lens type: plano-convex lens path



COLOUR SYSTEM

  • Colour mixing: RGBW / FC
  • Colour wheel: virtual colour wheel with macros
  • Macros: built-in white presets

DYNAMIC EFFECTS

  • Static mode: selection of static colour
  • Manual mode: manual adjustment of colour
  • Auto mode: built-in programs with execution speed adjustment

BODY

  • Body: sturdy die-cast aluminium body
  • Body colour: black

CONTROL

  • Protocols: DMX512
  • DMX channels: 5 / 7 / 10channel
  • Display: Graphic User Interface
  • Firmware upgrade: yes, via USB – DMX interface (UPBOX1) not included
  • Master/Slave: for synchronised operation of more units linked in a chain
ELECTRONICS

  • Dimmer: linear 0 ~ 100% electronic dimmer
  • Dimmer curves: 4 selectable dimming modes available
  • Strobe / shutter: 1 – 28 Hz, electronic
  • Operating temperature: -10° ~ +40°
  • LED Control: flicker free operation
  • Selectable PWM: 600 ~ 25.000 Hz





ELECTRICAL

  • Mains power supply: 100-240V – 50/60Hz
  • Max power consumption: 120W
  • Output (at 230V): 12 units on a single power line
  • Power factor: > 0,94

PHYSICAL

  • IP rating: 30
  • Cooling: active, silent operation
  • Suspension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
  • Signal connection: XLR 3p + 5p IN/OUT connectors
  • Power connection: Neutrik powerCON IN/OUT connectors
  • Dimensions (WxHxD): 262x350x261mm / 10.31”x13.78”x10.28”
  • Weight: 5,5kg / 12.13lbs



CERTIFICATIONS / APPROVALS

  • Certifications / Approvals: CE, UKCA, RCM



BOX CONTENT

  • 1 x VERSAPAR
  • 1 x 1,5 meters power cable (BARE END – NEUTRIK POWERCON)
  • User Manual
